Name: PP Manual Butt Fusion Welding Machine OEM Design
Brand: HEBEI ZEMO TECHNOLOGY CO., LTD.
SKU: Smd-B160/50M
Price: 50.00 USD
Availability: InStock

Thuis Producten Hand het Lassenmachine van de Uiteindefusie

PP Manual Butt Fusion Welding Machine OEM Design

Productdetails:

Plaats van herkomst:	China
Merknaam:	ZEMO
Certificering:	CE , ISO
Modelnummer:	Smd-B160/50M

Betalen & Verzenden Algemene voorwaarden:

Min. bestelaantal:	1 REEKS
Prijs:	negotiable
Verpakking Details:	Polywoodgevallen
Levertijd:	3-7 werkdagen na betaling
Betalingscondities:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Levering vermogen:	300 reeks/maand

Contact

Gedetailleerde productomschrijving

Productnaam:	De handMachine van de Stuiklasfusie	Pijpgrootte (mm:	50,63,75,90,110,125,140,160,
Het verwarmen Plaat Max. Temperaturen.:	270 ℃	Temp.deviation in oppervlakte (170-250 ℃):	≤±5℃
Het werk Voltage:	220V, 50/60HZ, enige fase	Het verwarmen plaatmacht:	1KW
Het schaven hulpmiddelmacht:	0.7KW	Totale Macht:	1.75KW
Gewicht:	44kG	Waarborg:	24 maanden
Markeren:	PP Manual Butt Fusion Welding Machine , OEM Manual Butt Fusion Welding Machine , Manual Butt Fusion Welder

Manual Butt Weld Fusion Machine Description

Manul Butt Weld Fusion Machine is able to weld pipes and fittings with material PE, PP and PVDF, operation easily and suitable for any complex work condition. It Consists of basic frame, hydraulic unit, planing tool, heating plate, support for planing tool& heating plate, and optional parts

Manual Butt Weld Fusion Machine Specification

product name		160MM Manual Butt Weld Fusion Machine
Model		SMD-B160/50M
Pipe size (mm)		50,63,75,90,110,125,140,160
Pipe material		PE PP PVDF PPR HDPE etc
Heating plate Max. Temperature		270℃
application		Butt Weld Fusion PE PP PVDF PPR HDPE etc
Temp.deviation in surface (170-250 ℃)		≤±7℃
Working Voltage		220V , 50/60HZ , single phase
Heating plate power		1KW
Planing tool power		0.7KW
Total Power		1.7KW
Weight		44KG
Packing	Cases	2 plywood cases
	Volume	0.31CBM

Manual Butt Weld Fusion Machine Advtange

Removable PTFE coated heating plate with separate temperature control system.
Electrical planning tool;
Be made of lightweight and high strength material; simple structure, small and delicate user friendly;
Low starting pressure ensures reliable welding quality of small pipes;
Separate two-channel timer shows time in soaking and cooling phases;
High-accurate and shockproof pressure meter in indicates clear readings.

Manual Butt Weld Fusion Machine Guarantee and Service

All designed according to ISO21307:2011(E),ISO12176-1 and DVS2207/1(08/2007)
International warranty: 24months.

label:

Contactpersoon: Jack Lu

Tel.: 13933031824

Fax: 86-0311-80826269
